Description

When there’s no such thing as too much power, start up the Bobcat T320 compact track loader! Tough grading, heavy pushing and high-flow attachment applications are no sweat for the T320’s impressive 92 horsepower engine.

SPECIFICATIONS

T320

Emissions Tier (EPA)

Tier 2

Engine Fuel

Diesel

Horsepower

92 HP

Turbocharged Engine

Yes

Rated Operating Capacity (SAE)

3100 lbs

Operating Capacity (50% of Tip)

4604 lbs

Tipping Load

9208 lbs

Operating Weight

9702 lbs

Travel Speed – High

6.6 mph

Travel Speed – Low

6.6 mph

Ground Pressure (Rubber)

4.2 psi

Fuel Tank

26 gal

Cooling System

3.6 gal

Pump Capacity

21.2 GPM

Auxiliary High Flow

37 GPM

Length

114.5 in

Length with Standard Bucket

142.9 in

Width

40 in

Width (with bucket)

 40in

Height

80.9 in

Height with Operator Cab

80.9 in

Height to Bucket Hinge Pin

128.8 in

Reach @ Maximum Height

36.5 in

Length of track on ground

63.7 in

Track Width

18 in

Track Width – Optional

12.6 in
